18W/8531G00 |
ÉϺ£¶«Ñ¶£ºwww.hifi-efax.com
| Characteristic sensitivity (2.83V / 1m) |
: |
87 dB | |
| Recommended frequency range |
: |
28 - 5000 Hz | |
| Free air resonance frequency, fs |
: |
28 Hz | |
| DC resistance, Re |
: |
5.8 ohm | |
| Voice coil inductance, Le |
: |
0.35 mH | |
| Effective piston area, Sd |
: |
150 cm² | |
| Moving mass incl. air, md |
: |
17.5 g | |
| Mechanical loss, Rm |
: |
0.6 Ns/m | |
| Force factor, BL |
: |
6.8 Tm | |
| Equivalent volume, Vas |
: |
59 ltr. | |
| Mechanical Q-factor, Qms |
: |
5.1 | |
| Electrical Q-factor, Qes |
: |
0.39 | |
| Total Q-factor, Qts |
: |
0.36 | |
| Excursion, lin./max. |
: |
¡À6.5 / ¡À11 mm | |
| Voice coil diameter |
: |
38 mm | |
| Rated power handling |
: |
60 W | |
| Net weight |
: |
1.75 kg |
