18W/8535-00 |
| Characteristic sensitivity (2.83V / 1m) |
: |
86.5 dB | |
| Recommended frequency range |
: |
26 - 3500 Hz | |
| Free air resonance frequency, fs |
: |
26 Hz | |
| DC resistance, Re |
: |
5.8 ohm | |
| Voice coil inductance, Le |
: |
0.3 mH | |
| Effective piston area, Sd |
: |
145 cm² | |
| Moving mass incl. air, md |
: |
15.5 g | |
| Mechanical loss, Rm |
: |
1.0 Ns/m | |
| Force factor, BL |
: |
5.7 Tm | |
| Equivalent volume, Vas |
: |
72 ltr. | |
| Mechanical Q-factor, Qms |
: |
2.5 | |
| Electrical Q-factor, Qes |
: |
0.45 | |
| Total Q-factor, Qts |
: |
0.38 | |
| Excursion, lin./max. |
: |
¡À5.0 / ¡À10 mm | |
| Voice coil diameter |
: |
38 mm | |
| Rated power handling |
: |
70 W | |
| Net weight |
: |
1.8 kg |
